Fig. S3
Early neural crest development and patterning are unaffected in wls-/-. Whole mount in situ hybridization of the indicated genes in wild-type and wls-/- embryos with head to the left in dorsal view (A,F) and lateral view (B-E, G-J). At all stages and genes examined, the expression does not differe between wild-type and wls-/- mutants. Markers used: sox10: early cNCC; dlx2a: migrating cNCCs; edn1: cNCC migration; sox9: cartilage formation; col2a: cartilage formation. |
