Fig. 3

Expression and Timing Requirement of med14 for Development

(A) Worsening of the log mutant phenotype by injection of morpholino (MO) targeting med14 (red arrowhead denotes somite defect).

(A′ and A′′) Somite structure of 3.5 dpf rhodamine phalloidin (RhPh) stained WT and MO-injected mutant embryos. Defects in muscle fiber patterns of mutant embryos injected with MO are shown (yellow arrowheads).

(B–D) RNA ISH analysis shows that med14 is broadly expressed at the one- and two-cell stage and at 12 hpf (“WT/MUT” denotes unknown genotype). At 24 hpf, broad med14 expression is undetectable in zygotic med14 mutants.

(E–K) Temporal rescue of the log mutant phenotype using Tg(hsp70:med14, α-crystallin:EGFP), with initial heat shock performed at the specified time, and then every 12 hr following until 5 dpf. Scale bars, 0.5 mm.

Expression Data
Gene:
Fish:
Anatomical Terms:
Stage Range: 2-cell to Prim-5

Expression Detail
Antibody Labeling
Phenotype Data
Fish:
Condition:
Knockdown Reagent:
Observed In:
Stage Range: Protruding-mouth to Day 5

Phenotype Detail
