FIGURE 7

ID

ZDB-IMAGE-250603-42

Genes

Publication

Ohyanagi et al., 2025 - Genetic Mechanism That Defines the Characteristic Neurogenesis Patterns in the Neural Plate Using Hes/her Genes During Early Vertebrate Development

All Figures

Figures for Ohyanagi et al., 2025


Figure Caption

FIGURE 7

Expression of Notch‐independent her genes in her6 mutants. Embryos obtained by heterozygous mating of her6 mutants (her6^+/Δ5) were examined for the expression of Notch‐independent her genes by WISH, followed by genotyping. Open arrowheads show weak downregulation. Numbers of the embryos with the indicated expression patterns and total scored embryos are shown in the bottom‐right. her6^+/− embryos were indistinguishable from her6^+/+ embryos, and both were scored together and referred to as her6^+/. Images for wild‐type (her6^+/+) embryos are shown as representatives. fp, floor plate; le, lateral ectoderm. See the legends to Figures 1 and 3 for other abbreviations. Scale bars, 200 μm.

Figure Data

Expression / Labeling details

Phenotype details
