ZFIN Image: Selland et al., 2018, Fig. S2


Figure Caption

Fig. S2

Alterations to rhombomere size in paralog group 1 hox mutants.

Wildtype embryos show the normal expression patterns for epha4a in r3/5 (A), krox20 in red in r3/5 and val in purple in r5/6 (E), and hoxa3a (I) and hoxb3a (M) in r5/6. Expression of all markers are unaffected in hoxb1a^−/− mutants (B,F,J,N). Hoxb1b^−/− mutants have an increase in the A-P extent of r3 as observed in epha4a (C) and krox20 (G) expression. The A-P extent of r4 is reduced in hoxb1b^−/− mutants as seen in the space between r3/5 staining of epha4a (C) and krox20 (G). The A-P extent of r5/6 is also slightly reduced in hoxb1b^−/− mutants as seen by val (G), hoxa3a (K) and hoxb3a (O) expression. Hoxb1a^−/−;hoxb1b^−/− mutants have a similar expansion or r3 and reduction in the A-P extent of r4 as evidenced by epha4a (D) and krox20 (H) expression. The A-P extent of r5/6 is also reduced in hoxb1a^−/−;hoxb1b^−/− mutants as seen by val (H), and hoxb3a (P) expression. Hoxb1a^−/−;hoxb1b^−/− mutants also have a decrease in the expression of hoxa3a in r6 (L). All embryos have been genotyped for hoxb1a^sa1191 and hoxb1b^ua1006. All embryos are dorsal views, anterior to the left, (A-D) 22hpf, (E-P) 18hpf. hpf, hours post fertilization.

Figure Data

Expression / Labeling details

Phenotype details

Acknowledgments

This image is the copyrighted work of the attributed author or publisher, and ZFIN has permission only to display this image to its users. Additional permissions should be obtained from the applicable author or publisher of the image.

Reprinted from Mechanisms of Development, 150, Selland, L.G., Koch, S., Laraque, M., Waskiewicz, A.J., Coordinate regulation of retinoic acid synthesis by pbx genes and fibroblast growth factor signaling by hoxb1b is required for hindbrain patterning and development, 28-41, Copyright (2018) with permission from Elsevier. Full text @ Mech. Dev.
