ZFIN Image: Dal-Pra et al., 2006, Fig. 6


Figure Caption

Fig. 6 Analysis of double chordin?noggin1 morphants with endomesodermal markers. (A?C) Expression of draculin (drl) specific of presumptive hematopoietic territory at 70% epiboly. (D?F) Expression of the paraxial marker myf5 at the 3-somite stage. (G?I) Expression of the cephalic mesendodermal marker follistatin1 (fst1) at 80% epiboly. (J?L) Expression of the prechordal plate marker hgg1 which labels the presumptive hatching gland at 75% epiboly. (M?O) Expression of the notochordal marker floating-head (flh) at 75% epiboly. (A, D, G, J, M) Wild-type embryos (B, E, H, K, N), 100 μM MO-chd-injected embryos (C, F, I, L, O) 100?800 μM chd-nog1 MOs-injected embryos. (A?C) Vegetal pole views, dorsal to the right. (D?F) Dorsal views anterior to the left. (G?O) Dorsal views, animal pole up.

Figure Data

Expression / Labeling details

Acknowledgments

This image is the copyrighted work of the attributed author or publisher, and ZFIN has permission only to display this image to its users. Additional permissions should be obtained from the applicable author or publisher of the image.

Reprinted from Developmental Biology, 298(2), Dal-Pra, S., F�rthauer, M., Van-Celst, J., Thisse, B., and Thisse, C., Noggin1 and Follistatin-like2 function redundantly to Chordin to antagonize BMP activity, 514-526, Copyright (2006) with permission from Elsevier. Full text @ Dev. Biol.
