Figure Caption
Fig. 8 AML1-ETO downregulates scl, leading to the early effects of AML1-ETO expression in primitive hematopoietic cells. (A) In situ hybridization of scl. AML1-ETO expression results in scl downregulation specifically in hematopoietic cells. The expression of scl in the head (asterisk), in the endothelial primordium (arrowhead), and in the posterior tail region (arrow) was not affected. (B) In situ hybridization of gata1, mpo and fluorescent images of zpu.1-EGFP transgenic zebrafish. Injections of scl mRNA restored gata1 expression and reversed pu.1 and mpo induction in Tg(hsp:AML1-ETO) embryos.
Figure Data
Acknowledgments
This image is the copyrighted work of the attributed author or publisher, and
ZFIN has permission only to display this image to its users.
Additional permissions should be obtained from the applicable author or publisher of the image.
Full text @ Development
