Fig. S2

ID

ZDB-IMAGE-071005-6

Genes

Publication

Hogan et al., 2006 - Specification of the Primitive Myeloid Precursor Pool Requires Signaling through Alk8 in Zebrafish

All Figures

Figures for Hogan et al., 2006


Figure Caption

Fig. S2 Expression of Markers of Myeloid and Endothelial Terminal Differentiation in lost-a-fin Mutants Markers of myeloid terminal differentiation were vastly reduced in lost-a-fin, but tie2 expression in differentiating vascular endothelial cells was normal. (A–D) The expression of l-plastin (24 hpf) (A) and myeloperoxidase (mpo) (30 hpf) (C) was vastly reduced in lost-a-fin mutants (B and D), mutant genotype was determined by the loss of the ventral tail fin. (E–H) The expression of tie2 (24 hpf) (E and G) was normal in lost-a-fin mutants (F and H), mutant genotype was determined by the loss of the ventral tail fin. All panels show lateral views except (G) and (H), which are dorsal views. Arrows in (E) and (F) and brackets in (G) and (H) indicate vascular staining. n > 30 progeny were analyzed in each experiment from crosses of known heterozygotes.

Figure Data

Expression / Labeling details
