Fig. 6

ID
ZDB-IMAGE-060605-13
Genes
Publication
Gupta et al., 2006 - BMP signaling restricts hemato-vascular development from lateral mesoderm during somitogenesis
All Figures
Figures for Gupta et al., 2006
Figure Caption

Fig. 6 Both Lmo2+ and Gata1+ hematopoietic cells are restricted by BMP signaling. Representative embryos are shown that are either control (A,C,E,G) or derived from fertilized eggs injected with either I(lmo2:δBR)I (B,D) or I(gata1:δBR)I (F,H), and analyzed for gene expression by in situ hybridization. The markers tested are as indicted: (A,B) scl; (C,D) lmo2; (E,F) gata1; (G,H) flk1. Expression of both scl and lmo2 is enhanced by expression of the mutant receptor in Lmo2+ cells (arrowheads in B and D), while gata1 (the hematopoietic marker; arrowheads) but not flk1 (the endothelial marker; arrows) is enhanced when the receptor is expressed in Gata1+ cells (E-H). Views are flat-mounted dorsal, anterior towards the left (A-F) or lateral, anterior towards the left (G,H).

Figure Data
Acknowledgments
This image is the copyrighted work of the attributed author or publisher, and ZFIN has permission only to display this image to its users. Additional permissions should be obtained from the applicable author or publisher of the image. Full text @ Development
