FIGURE 4

Granule cell morphology and Actin organization in wild‐type and fat2 mutant larvae. (a–d) Expression of Venus in 5‐dpf Tg(cbln12:Venus) larvae in wild‐type (a) and fat2^{nub128/nub128} backgrounds (b) (n = 5 for each background), and expression of mCherry in 5‐dpf Et(hsp70l:GAL4FFDMC)nkhspGFFDMC90AEt; Tg(10xUAS:LIFEACT‐mCherry) larvae in wild‐type (c) and fat2^{nub128/nub128} backgrounds (d) (n = 5 for each background). Signals were detected by immunostaining. Dorsal views with anterior to the left. (ai–di) Higher magnification views of the corpus cerebelli. (aii–dii) Higher magnification views of granule cell axons in the caudolateral lobes. Arrowheads indicate branched bundles. Scale bar: 100 μm in (a) (applies to a–d) and (aa) (applies to ai–di and aii–dii). Regions of the cerebellum, including CCe, EG, LCa, and TL, are indicated in the images. Images are representative of the samples examined, and the observed phenotypes were consistent across all samples in each condition (n = 5).

Expression Data

Antibodies:	Ab1-DsRed Ab22-gfp
Fish:	nub24Tg (AB) chi4Tg; nkhspGFFDMC90AEt (AB) fat2^{nub128/nub128}; chi4Tg; nkhspGFFDMC90AEt (AB) fat2^{nub128/nub128}; nub24Tg (AB)
Anatomical Term:	cerebellar granule cell axon
Stage:	Day 5

Expression Detail

Antibody Labeling

Phenotype Data

Fish:	fat2^{nub128/nub128}; chi4Tg; nkhspGFFDMC90AEt (AB) fat2^{nub128/nub128}; nub24Tg (AB)
Observed In:	cerebellar granule cell axon
Stage:	Day 5

Phenotype Detail
