Fig. 9

Enriched Gene Ontology (GO) terms for differentially expressed genes (DEGs) between experimental groups. A. GO enrichment analysis of DEGs for a EE2-treated triploid (3n + EE2) versus triploid control (3n) zebrafish gonads showing enrichment in pathways related to steroid biosynthesis and lipid metabolism. B. GO enrichment analysis of DEGs for diploid control (2n) vs EE2-treated triploid (3n + EE2) zebrafish gonads, highlighting pathways involved in growth factor stimuli, programmed cell death and stem cell differentiation. GO terms most relevant to our process of interest are indicated by red arrowheads. The size of the black circles in the right side indicates the number of genes involved in each process, while the colours represent the adjusted p-value (p.adjust), with red color indicating stronger statistical significance. (For interpretation of the references to color in this figure legend, the reader is referred to the Web version of this article.)

Expression Data

Expression Detail

Antibody Labeling

Phenotype Data

Phenotype Detail

Acknowledgments

This image is the copyrighted work of the attributed author or publisher, and ZFIN has permission only to display this image to its users. Additional permissions should be obtained from the applicable author or publisher of the image.

Reprinted from Molecular and Cellular Endocrinology, , Torres-Martínez, A., Tichopád, T., Pšenička, M., Franěk, R., Triploidy alters hormonal and paracrine signaling to promote male development in zebrafish, 112740112740, Copyright (2026) with permission from Elsevier. Full text @ Mol. Cell. Endocrinol.
