FIGURE

Figure 2

ID

ZDB-FIG-230124-151

Publication

Grossi et al., 2022 - Lasp1 Expression Is Implicated in Embryonic Development of Zebrafish

Other Figures

All Figure Page

Back to All Figure Page

Figure 2

Detection of Lasp1 protein expression in various organs and tissues of zebrafish, including the muscle, the eye, the brain, the liver and the gastrointestinal tract. (A) Histological analysis by hematoxylin and eosin staining of muscle fiber, eye, brain, liver and intestinal tract tissue sections. Pancreas (a), liver (b), and intestine (c) samples are indicated. Magnification: 4× and 20×. (B) Immunofluorescence detection of Lasp1 (green) in the selected tissue sections by immunohistochemistry with Alexa photosensitive antibodies. Magnification: 20× and 63× (blue: DAPI; green: FITC). Scale bars are placed at the lower left corner of each image and correspond to 100 µm for 4× and 20× magnification and to 30 µm for 63× magnification.

Expression Data

Gene:	lasp1
Antibody:	Ab1-lasp1
Fish:	AB
Anatomical Terms:	brain eye gut liver muscle
Stage:	Adult

Expression Detail

Antibody Labeling

Phenotype Data

Phenotype Detail
