FIGURE

Fig. 3

ID

ZDB-FIG-220912-122

Publication

Born et al., 2022 - eif4ebp3l-A New Affector of Zebrafish Angiogenesis and Heart Regeneration?

Other Figures

All Figure Page

Back to All Figure Page

Fig. 3

In the injured area the mRNA expression of eif4ebp3l decreased in the early phase of zebrafish heart regeneration. (A–C) RNAscope of the apex of Tg(fli1:eGFP) zebrafish heart at 7 dpci, 21 dpci and 60 dpci. In the merged image mRNA expression of eGFP is visualized in green and eif4ebp3l in orange. Dashed lines highlight the approximate border to the IA. (A) Eif4ebp3l was highly expressed in the healthy myocardium and downregulated in IA. (B,C) With progressive regeneration of the zebrafish heart, the expression of eif4ebp3l recovered in the IA and reached the mRNA expression level of the healthy myocardium at 60 dpci. Scale bar = 100 µm.

Expression Data

Expression Detail

Antibody Labeling

Phenotype Data

Phenotype Detail

Acknowledgments

This image is the copyrighted work of the attributed author or publisher, and ZFIN has permission only to display this image to its users. Additional permissions should be obtained from the applicable author or publisher of the image. Full text @ Int. J. Mol. Sci.
