Figure 15

Partial apex resection surgery at seven days and heart explants at 5D PO and 1W PO-Hematoxylin and Eosin (H & E) histology of seven-day surgery heart explants obtained five days post-operation (5D PO): (A) Seven-day surgery heart from piglet #007. (B) Seven-day surgery heart from piglet #008. (C) Seven-day surgery heart from piglet #029. (D) Seven-day surgery heart from piglet #031. H & E histology of seven-day surgery heart explants obtained one-week post-operation (1W PO): (E) Seven-day surgery heart from piglet #009. (F) Seven-day surgery heart from piglet #010. (G) Seven-day surgery heart from piglet #016. (H) Seven-day surgery heart from piglet #028. Histological images were taken at 4× magnification (Scale bar = 200 μm). H & E: pink–cytoplasm; blue–nuclei; intense red–erythrocytes.
