FIGURE
Figure 8
- ID
- ZDB-FIG-210310-112
- Publication
- Zizioli et al., 2021 - Development of BCR-ABL1 Transgenic Zebrafish Model Reproducing Chronic Myeloid Leukemia (CML) Like-Disease and Providing a New Insight into CML Mechanisms
- Other Figures
- All Figure Page
- Back to All Figure Page
Figure 8
Hematoxylin-eosin staining on paraffin embedded longitudinal section (8 um) in wild type (WT) and tg BCR-ABL1 fish. Spleen (A,B) and kidney (C,D) are reported. Different histological and morphological structures are indicated blue arrows. (Magnification 40×) Bar 30 um. |
Expression Data
Expression Detail
Antibody Labeling
Phenotype Data
| Fish: | |
|---|---|
| Condition: | |
| Observed In: | |
| Stage: | Adult |
Phenotype Detail
Acknowledgments
This image is the copyrighted work of the attributed author or publisher, and
ZFIN has permission only to display this image to its users.
Additional permissions should be obtained from the applicable author or publisher of the image.
Full text @ Cells
