ZFIN ID: ZDB-FIG-200514-14
Koth et al., 2020 - Runx1 promotes scar deposition and inhibits myocardial proliferation and survival during zebrafish heart regeneration. Development (Cambridge, England)   147(8) Full text @ Development
ADDITIONAL FIGURES
EXPRESSION / LABELING:
Gene:
Antibody:
Fish:
Condition:
Anatomical Terms:
Stage: Adult
PHENOTYPE:
Fish:
Condition:
Observed In:
Stage: Adult

Fig. 8 Myh11-positive endocardial cells and thrombocytes retain their double identity. (A-B′) In situ hybridisation for itga2b combined with immunohistochemistry for Citrine and Myh11. Arrowheads indicate Myh11-positive itga2b-positive thrombocytes present in the wild-type wound that are largely missing in the runx1 mutant wound at 7 dpci. (C-D′) In situ hybridisation for itga2b combined with immunohistochemistry for Myh11 with nuclear Dapi staining. Both the endocardium (inset) and thrombocytes (arrowheads) still express Myh11 in the wild-type wound at 14 dpci, while being absent in the mutant wound. v, ventricle; w, wound. Scale bars: 100 μm.

Gene Expression Details
Gene Antibody Fish Conditions Stage Qualifier Anatomy Assay
itga2b ox1Tg cold damage: cardiac ventricle Adult endocardium ISH
Adult thrombocyte ISH
runx1hg1/hg1; ox1Tg cold damage: cardiac ventricle Adult endocardium ISH
Adult Not Detected thrombocyte ISH
Antibody Labeling Details
Antibody Assay Fish Conditions Stage Anatomy
Ab2-myh11 IHC ox1Tg cold damage: cardiac ventricle Adult endocardium
IHC Adult thrombocyte
IHC runx1hg1/hg1; ox1Tg cold damage: cardiac ventricle Adult endocardium
Phenotype Details
Fish Conditions Stage Phenotype
runx1hg1/hg1; ox1Tg cold damage: cardiac ventricle Adult endocardium itga2b expression decreased distribution, abnormal
Adult endocardium Ab2-myh11 labeling decreased distribution, abnormal
Adult thrombocyte itga2b expression absent, abnormal
