Figure 3

Whole mount RNA in situ hybridization of slc2a3a at early embryonic stages [18–36 hours post fertilization (hpf)]. Pictures in the left column depict alternating lateral (A,C,E,G) and dorsal (B,D,F,H) views. Anterior is to the left. Higher magnifications (a₁–h₃) corresponding to boxes in (A–H). Arrowheads indicate examples of labeled cells or cell populations. Note staining in spinal cord, hindbrain, ventral midbrain, ventral thalamus, ventral telencephalon and epiphysis. Two bilateral rows, one medially (black arrowheads) and one laterally (white arrowheads) of positive cells are situated in the ventral hindbrain along the floor plate (f₂ and h₂). For abbreviations of anatomical terms see Table 1. Scale bars in (A), 100 μm and pertains to (A–H); scale bar in a₁, 50 μm and pertains to a₁–h₃.

Expression Data

Gene:	slc2a3a
Fish:	AB
Anatomical Terms:	epiphysis hindbrain hindbrain ventral region midbrain ventral region spinal cord spinal cord neural tube anterior region ventral telencephalon ventral thalamus
Stage Range:	14-19 somites to Prim-25
