Lechermeier et al., 2019 - Transcript Analysis of Zebrafish GLUT3 Genes, slc2a3a and slc2a3b, Define Overlapping as Well as Distinct Expression Domains in the Zebrafish (Danio rerio) Central Nervous System. Frontiers in molecular neuroscience 12:199 Full text @ Front. Mol. Neurosci.

ADDITIONAL FIGURES

EXPRESSION / LABELING:

Gene:	slc2a3b
Fish:	AB
Anatomical Terms:	dorsal telencephalon granular layer corpus cerebelli granular layer valvula cerebelli medulla oblongata periventricular grey zone preoptic area telencephalon torus longitudinalis
Stage:	Adult

Figure 8

RNA in situ hybridization of adult expression of slc2a3b. Pictures show cross sections of an adult zebrafish brain (80 μm) from anterior to posterior as indicated in the scheme. Panels (A’–J’) are high magnifications of boxed areas in (A–J). Black arrowheads in (A’,B’,J’) indicate example of single-positive cells. Detailed descriptions can be found in the text, for abbreviations see Table 1. Scale bar in (A), 100 μm and pertains to (A–J); scale bars in (A’–J’), 20 μm.

Gene Expression Details

Gene	Fish	Conditions	Stage	Anatomy	Assay
slc2a3b	AB	control	Adult	dorsal telencephalon	ISH
			Adult	granular layer corpus cerebelli	ISH
			Adult	granular layer valvula cerebelli	ISH
			Adult	medulla oblongata	ISH
			Adult	periventricular grey zone	ISH
			Adult	preoptic area	ISH
			Adult	telencephalon	ISH
			Adult	torus longitudinalis	ISH

Antibody Labeling Details No data available

Phenotype Details No data available
