FIGURE

Fig. 5

ID

ZDB-FIG-180509-14

Publication

Kumar et al., 2017 - Rnf152 Is Essential for NeuroD Expression and Delta-Notch Signaling in the Zebrafish Embryos

Other Figures

All Figure Page

Back to All Figure Page

Fig. 5

WISH analysis of rnf152 MO using deltaD as a probe. (A, D) WT embryos, (B, E) embryos injected with 5′ mismatch as control, and (C, F) rnf152 MO. deltaD transcripts were abundant in the ventral midbrain and rhombomeres of the brain but low in the eyes of WT (A, D) and 5′ mismatch (B, D). However, level of deltaD transcripts was significantly reduced in the respected tissues (C, F). Red arrowheads indicate the eye, midbrain, and hindbrain (n = 3). Scale bars (A–F): 50 μm.

Expression Data

Gene:	dld
Fish:	WT WT + MO1-rnf152
Knockdown Reagent:	MO1-rnf152
Anatomical Terms:	eye forebrain hindbrain midbrain midbrain hindbrain boundary
Stage:	Prim-5

Expression Detail

Antibody Labeling

Phenotype Data

Fish:	WT + MO1-rnf152
Knockdown Reagent:	MO1-rnf152
Observed In:	eye forebrain hindbrain midbrain midbrain hindbrain boundary
Stage:	Prim-5

Phenotype Detail
