Fig. 1

Mackay et al., 2015 - Vitamin K reduces hypermineralisation in zebrafish models of PXE and GACI
Other Figures
All Figure Page
Back to All Figure Page
Fig. 1

The gräte mutant phenotype is characterised by hypermineralisation in the skin and axial skeleton. (A) Alizarin Red staining of embryos at 8days post-fertilisation (dpf), demonstrating hypermineralisation along the vertebral column (arrowheads). Scale bar: 1mm. (B) Adult fish are viable, but feature a curved spine and reduced length. Scale bar: 1cm. (C) grt-/- embryos (ventral view) with enhanced mineralisation in craniofacial elements (arrowheads). (D) Skin mineralisation is infrequently seen in grt+/- and grt-/- embryos (D′, ventral view). (E) Representative images showing the area quantified by the mineralisation assay used in this and in subsequent figures. (F) Vertebral mineralisation in grt-/- embryos proceeds faster than in wild type, leading to (G) vertebral fusion from 6dpf onwards. (H,J) Alizarin Red staining at 6weeks post fertilisation (wpf) reveals a thickened, curved spine in grt-/- fish; confocal images (I,K) of the boxed regions reveal mineralised nodules on the margins of the intervertebral space (arrowheads). Scale bars: 0.1mm.

Expression Data

Expression Detail
Antibody Labeling
Phenotype Data
Observed In:
Stage Range: Day 6 to Adult

Phenotype Detail
This image is the copyrighted work of the attributed author or publisher, and ZFIN has permission only to display this image to its users. Additional permissions should be obtained from the applicable author or publisher of the image. Full text @ Development
