Fig. 2
Detection of GFP- and LacZ-expressing cells in transgenic fish. A, GFP expression at the olfactory region (OR). B–D, GFP or LacZ cells in the olfactory bulb (OB) and telencephalon (Tel) at 3–8 d (days). E, lacZ cells and axons in the brain at 16 dpf. Hyp, hypothalamus. F–G, At 1 month (m) and 4 months, fluorescent axonal extensions are at OB, Tel and POA (preoptic area). Red arrows indicate cell bodies, yellow arrows indicate axons. A, C, F, G, GFP cells; B, D, E, LacZ-expressing cells. The anterior is towards the left in all panels. A, B, F, G, ventral view; C-E, dorsal view. |
Expression Data
| Gene: | |
|---|---|
| Fish: | |
| Anatomical Terms: | |
| Stage Range: | Long-pec to Adult |
