Fig. 1

Cyp26 expression partially overlaps with cardiovascular progenitors. (A-B2) Whole-mount double in situ hybridization of cyp26a1 and cyp26c1 expression (red) relative to nkx2.5 (blue) in wild-type embryos at 8 s. (C-D2) cyp26a1 and cyp26c1 expression relative to etv2 (blue) in wild-type embryos at 8 s. A2-D2 correspond to boxed areas in A-D, respectively. All images are dorsal views with anterior upwards. Black arrows in A2-D2 indicate cells with overlapping expression. White arrows in C2 and D2 indicate cells without overlapping expression.

Expression Data

Genes:	cyp26a1 cyp26c1 etsrp nkx2.5
Fish:	WT
Anatomical Terms:	anterior lateral plate mesoderm cardiovascular system heart primordium
Stage:	5-9 somites
