Fig. 5

Notch negatively regulates nr2f2 in the zebrafish vasculature, but not via Sox. (A and B) Whole mount in situ hybridization of 24 hpf control (A) and Tg[fli1a:GV-EcRF];Tg[UAS:N3ICDmyc] double transgenic (B) animals treated with tebufenozide from 8 hpf to 28 hpf, probed for nr2f2. Blue arrowheads show the position of the posterior cardinal vein. The inset numbers in panel B show the number of in situ-stained embryos exhibiting strongly reduced vascular expression over the total number of embryos examined. (C and D) Whole mount in situ hybridization of 24 hpf control (C) and kdrl:Su[H]DBM-2A-mCherry injected (D) animals, probed for nr2f2. Blue arrowheads show position of the posterior cardinal vein, red arrowheads show ectopic nr2f2 expression in the dorsal aorta. The inset numbers in panel D show the number of in situ-stained embryos exhibiting patches of strong ectopic nr2f2 expression in the dorsal aorta over the total number of embryos examined. (E–H) Whole mount in situ hybridization of 24 hpf control (E and G) and Tg[fli1a:GV-EcRF];Tg[UAS:N3ICDmyc] double transgenic (F and H) animals treated with tebufenozide from 8 hpf to 24 hpf, probed for sox7 (E and F) or sox18 (G,H). The inset numbers in panels F and H show the number of N3ICDmyc-expressing in situ-stained embryos exhibiting sox7 or sox18 expression comparable to that in controls, over the total number of embryos examined. Rostral is to the left and dorsal is up in all image panels. Scale bars, 100µm.

Expression Data

Genes:	nr2f2 sox7 sox18
Fish:	kca3Tg; y273Tg
Condition:	chemical treatment: tebufenozide
Anatomical Terms:	dorsal aorta posterior cardinal vein
Stage:	Prim-5

Expression Detail

Antibody Labeling

Phenotype Data

Fish:	kca3Tg; y273Tg
Condition:	chemical treatment: tebufenozide
Observed In:	dorsal aorta blood vessel endothelial cell fate specification posterior cardinal vein venous blood vessel development vascular endothelium Notch signaling pathway
Stage:	Prim-5

Phenotype Detail

Acknowledgments

This image is the copyrighted work of the attributed author or publisher, and ZFIN has permission only to display this image to its users. Additional permissions should be obtained from the applicable author or publisher of the image.

Reprinted from Developmental Biology, 390, Swift, M.R., Pham, V.N., Castranova, D., Bell, K., Poole, R.J., Weinstein, B.M., SoxF factors and Notch regulate nr2f2 gene expression during venous differentiation in zebrafish, 116-25, Copyright (2014) with permission from Elsevier. Full text @ Dev. Biol.
