Fig. 5

Whole mount in situ hybridization of CS/DS glycosyltransferases at 72 hpf. Lateral views of larvae (left) and dorsal views of larval heads (right), showing the expression patterns of csgalnact1 (A,B), csgalnact2 (C,D), chsy3 (E,F), chpf2 (G,H), chpfa (I,J), and chpfb (K,L). Arrows indicate the position for sections shown in Figure 6. BVZ, brain ventrical zone; PC, pharyngeal cartilage; EP, ethmoid plate; G, gut; OS, olfactory system; PD, pronephric duct; PZ, proliferating zone of retina; SC, spinal cord.

Expression Data

Genes:	chpf2 chpfa chpfb chsy3 csgalnact1a csgalnact2 (all 6)
Fish:	WT
Anatomical Terms:	brain ciliary marginal zone cranial cartilage eye gut head midbrain otic vesicle pectoral fin pronephric duct spinal cord ventricular zone (all 12)
Stage:	Protruding-mouth
