Fig. 4

Primitive erythropoiesis is not affected by pak4 knockdown. Two specific markers for erythroid precursors, gata1a and hbbe3 in the posterior blood lineage and intermediate cell mass were unaffected by pak4 MO injection at 15-somite (A and B) or 24 hpf (C–F).

Expression Data

Genes:	gata1a hbbe3
Fish:	EKW EKW + MO3-pak4 + MO4-pak4 + MO5-pak4
Knockdown Reagents:	MO3-pak4 MO4-pak4 MO5-pak4
Anatomical Terms:	blood island erythroid progenitor cell intermediate cell mass of mesoderm erythroid progenitor cell
Stage Range:	14-19 somites to Prim-5

Expression Detail

Antibody Labeling

Phenotype Data

Fish:	EKW + MO3-pak4 + MO4-pak4 + MO5-pak4
Knockdown Reagents:	MO3-pak4 MO4-pak4 MO5-pak4
Observed In:	primitive hemopoiesis
Stage Range:	14-19 somites to Prim-5

Phenotype Detail
