Fig. 8

Cdh2 is required for maintaining the interaction between the pioneer trailing axon and follower FMBNs. Maximum projection images of Tg(zCREST1:membRFP) embryos. (A-D) In uninjected control embryos at (A) 18 hpf, (B) 20 hpf, (C) 22 hpf and (D) 24 hpf, the trailing axon (arrows) of the pioneer neuron (arrowheads) maintains contact with follower FBMNs. (E-H) In Cdh2MO-injected embryos, the interaction between the trailing axon of the pioneer neuron and follower FBMNs is reduced or absent; examples at (E) 18 hpf, (F) 20 hpf, (G) 22 hpf and (H) 24 hpf. Arrowheads indicate the pioneer neuron. Arrow indicates the trailing axon. Scale bar: 20 μm.

Expression Data

Gene:	mRFP
Antibody:	zn-12
Fish:	ch100Tg + MO1-cdh2
Knockdown Reagent:	MO1-cdh2
Anatomical Terms:	branchiomotor neuron lateral longitudinal fasciculus medial longitudinal fasciculus
Stage Range:	20-25 somites to Prim-5

Expression Detail

Antibody Labeling

Phenotype Data

Fish:	ch100Tg + MO1-cdh2
Knockdown Reagent:	MO1-cdh2
Observed In:	branchiomotor neuron branchiomotor neuron neuron migration medial longitudinal fasciculus neuron cell-cell adhesion
Stage Range:	20-25 somites to Prim-5

Phenotype Detail
