Fig. S4

crabp2a knockdown phenotypes can be partially rescued by crabp2a mRNA. (A-F) Whole-mount in situ hybridization for pax2a, krox20 and hoxb4; dorsal views, anterior to the left. Embryos co-injected with Crabp2a-MO and either 100 pg (C) or 200 pg crabp2a rescue mRNA (D-F) and treated with 5 nM RA showed an improvement in krox20 expression compared with Crabp2a-MO-injected embryos treated with 5 nM RA (B), but rescue is not complete compared with wild-type embryos treated with 5 nM RA (A). (G) Proportions of embryos with each phenotype. Results are also summarized in Fig. 4C.
