Fig. 2

Expression of Nsf in the CNS and lateral line organ (5 dpf).

A, An antibody against human NSF protein labels the larval nervous system (5 dpf). B, Labeling is absent in nsf^st53 mutants. Images are projections of 5 optical sections of 10 μm thickness. Scale bar, 100 μm. C-F, Confocal projections (10×1 μm sections) of anti-NSF (red) and Ribeye b (Blue) in TgBAC(neurod:EGFP)nl1 transgenic fish. Nsf signal colocalized with anti-GFP (green) in the afferent nerve, and was also in Ribeye b-positive hair cells. Scale bar, 10 μm.

Expression Data

Gene:	EGFP
Antibodies:	Ab1-nsf Ab3-ctbp2l
Fish:	WT nsfa^st53/st53 nl1Tg
Anatomical Terms:	lateral line nerve nervous system neuromast hair cell
Stage:	Day 5

Expression Detail

Antibody Labeling

Phenotype Data

Phenotype Detail
