Fig. 2

cd63 transcript.

A & B. Location of cd63 transcript as revealed by ISH, using a probe against cd63. Developmental stages are noted below with hpf (hours post fertilisation) in brackets. In the top panel of B (I–IV), the top row gives the lateral view, bottom row ventral. In BI, arrows indicate the first expression in the pre-polster. cd63 expression continues (BII–VII). Expression in the hatching gland is indicated in BVII and BVIII, by arrows. C. RT-PCR time course using single embryos. PCR primers are indicated on the right, ef1 is a ubiquitous transcription factor used as a control. Numbers indicate ladder position in base pairs. Developmental stages are indicated at the top of the figure, each carried out in duplicate. This gel is representative of three replicates.

Expression Data

Gene:	cd63
Fish:	WT
Anatomical Terms:	anterior axial hypoblast hatching gland polster whole organism
Stage Range:	1-cell to Long-pec
