Fig. 4

Characterization of otpb.A expression in dopaminergic and neuroendocrine cells. Embryos at 72 hpf, Tg(otpb.A:GAL4)^zc57, Tg(UAS:GFP). Scale bar is 50 μm. (A–A3) Confocal z-stack projection of whole-mount embryos double-labeled for GFP and for TH immunohistochemistry, ventral views, anterior to the top. (B) and (C) Plastic horizontal sections of double-labeled Tg(otpb.A:GAL4)^zc57; Tg(UAS:GFP) embryos at 72 hpf, anterior to the top. Higher magnification inset showing co-localization is indicated by yellow boxed area and is shown at bottom right of each panel. (B–B3) Labeled for GFP antibody (B) and slc6a3 mRNA (B2), GFP-positive neurons in the diencephalon co-express slc6a3, confirming their identity as dopaminergic. (C–C3) Labeled for GFP antibody (C) and isotocin mRNA (C2), rostral diencephalon GFP-positive NPO neurons co-express GFP and isotocin.

Expression Data

Genes:	EGFP oxt slc6a3 th
Fish:	nkuasgfp1aTg; zc57Tg
Anatomical Terms:	diencephalon dopaminergic neuron preoptic area neurosecretory neuron preoptic area peptidergic neuron
Stage:	Protruding-mouth

Expression Detail

Antibody Labeling

Phenotype Data

Phenotype Detail

Acknowledgments

This image is the copyrighted work of the attributed author or publisher, and ZFIN has permission only to display this image to its users. Additional permissions should be obtained from the applicable author or publisher of the image.

Reprinted from Developmental Biology, 352(2), Fujimoto, E., Stevenson, T.J., Chien, C.B., and Bonkowsky, J.L., Identification of a Dopaminergic Enhancer Indicates Complexity in Vertebrate Dopamine Neuron Phenotype Specification, 393-404, Copyright (2011) with permission from Elsevier. Full text @ Dev. Biol.
