Fig. S2

Morphological phenotype of cam-kii inhibitors morphants. Embryos that received 10 ng p53, cam-kiin1, or cam-kiin2, or combined both plus p53 MO were examined at 24 hr postfertilization (HPF). Embryos injected with p53 MO exhibited normal development. cam-kiin1 or cam-kiin2 or combined both plus p53 morphants were subdivided into wild type and mild phenotype as described in the text.

Expression Data

Expression Detail

Antibody Labeling

Phenotype Data

Fish:	WT + MO1-camk2n1a + MO4-tp53 WT + MO1-camk2n2 + MO4-tp53
Knockdown Reagents:	MO1-camk2n1a MO1-camk2n2 MO4-tp53
Observed In:	brain brain morphogenesis eye head midbrain midbrain hindbrain boundary optic tectum pericardium post-vent region somite somitogenesis trunk ventricular system whole organism
Stage:	Prim-5
