Fig. 6

Transmission electron microscopy (TEM) revealed abnormal ultrastructural morphology in the intestine of cdx1b morphants. A-D: EM sagittal sections of the intestinal bulb (A, C) and mid-intestine (B, D) of 80-hr post-fertilization (hpf) wild type (A, B) and cdx1b MO-injected (C, D) embryos. E-H: EM sagittal sections of the intestinal bulb (E, G) and mid-intestine (F, H) of 96-hpf wild type (E, F) and cdx1b MO-injected embryos (G, H). Arrows indicate the locations of goblet cells in the mid-intestine. Scale bars =10 μm.

Expression Data

Expression Detail

Antibody Labeling

Phenotype Data

Fish:	WT + MO1-cdx1b
Knockdown Reagent:	MO1-cdx1b
Observed In:	enterocyte enterocyte microvillus goblet cell secretory granule intestinal bulb enterocyte intestinal bulb microvillus mid intestine enterocyte mid intestine goblet cell mid intestine microvillus (all 8)
Stage Range:	Protruding-mouth to Day 4

Phenotype Detail
