Fig. 4

The effect of the twd^rw685 mutation is specific to neuronal migration. (A-L) Commissural axons (arrowheads) labeled with zn-5 antibody at 36 hpf (A,B; lateral view, rostral towards the left), reticulospinal neurons retrogradely labeled with rhodamin-dextran (RDX) at 5 dpf (C,D; ventral view, rostral towards the top), Gad1/2-positive neurons at 48 hpf (E,F; cross-sections, dorsal towards the top), Lhx2/9-positive neurons at 48 hpf (G,H; cross-sections, dorsal towards the top), aPKC at 30 hpf (I,J; cross-sections, dorsal towards the top) and ZO-1 at 30 hpf (K,L; cross-sections, dorsal towards the top) are labeled (red) in the wild-type (A,C,E,G,I,K) and twd^rw685 mutant (B,D,F,H,J,L) embryos.

Expression Data

Gene:	GFP
Antibodies:	Ab1-gad Ab1-prkcz Ab1-tjp1 Ab13-GFP zn-5
Fish:	rw0Tg gmds^rw685/rw685; rw0Tg
Anatomical Terms:	hindbrain bicellular tight junction hindbrain nucleus neuron white matter axon
Stage Range:	Prim-15 to Day 5

Expression Detail

Antibody Labeling

Phenotype Data

Fish:	rw0Tg gmds^rw685/rw685; rw0Tg
Observed In:	establishment of apical/basal cell polarity
Stage:	Prim-15

Phenotype Detail
