Fig. 2

Visualization and live imaging of vagus motor nuclei in isl1:GFP transgenic zebrafish. (A) Fluorescent images of the hindbrain of the isl1:GFP transgenic zebrafish. (a) Dorsal view (rostral towards the top) and (b) cross-section (dorsal towards the top) at the broken line shown in a. (B) Time-lapse imaging of the development of the vagus motor nuclei (upper row), accompanied by the schematic diagrams (lower row; dorsal towards the top). dlX, dorsolateral motor nucleus of the vagus; mmX, medial motor nucleus of the vagus; SM, spinal motor neurons.

Expression Data

Gene:	GFP
Fish:	rw0Tg
Anatomical Terms:	facial nerve motor nucleus spinal cord motor neuron trigeminal motor nucleus vagal lobe
Stage Range:	Prim-5 to Long-pec

Expression Detail

Antibody Labeling

Phenotype Data

Phenotype Detail
