Fig. 5

Iridophore phenotype and ltk expression patterns in sox10 mutants.
A, B) Iridophores (arrows) are prominent in 5 dpf WT (A), but almost absent in sox10^m618 (1 residual cell is seen here in the dorsal stripe)(B) and sox10^t3 (not shown) mutants. C–H) ltk expression (purple, arrows) patterns in WT (C, E, G) and sox10^t3 mutants (D, F, H); stages as shown. Arrows indicate ltk-expressing cells on eye and in premigratory NC (24 and 30 hpf) and in iridoblasts (48 hpf); insets show dorsal view of posterior trunk and tail. Arrowhead labels ltk-expressing cells of lateral patch.

Expression Data

Gene:	ltk
Fish:	WT sox10^t3/t3
Anatomical Terms:	immature eye iridophore pigment cell trunk neural crest
Stage Range:	Prim-5 to Long-pec

Expression Detail

Antibody Labeling

Phenotype Data

Phenotype Detail
