Fig. S8
hsp90a morphants show upregulation of chaperone transcripts whereas hsp90a2 morphants do not. Lateral views of wild-type, slou45, hsp90a morphant, hsp90a2 morphant and hsp90a/hsp90a2 double morphants (condition indicated above individual embryos) examined for expression of hspa81 (A), unc45b (B) and hsp90a (C). Abrogation of hsp90a2 activity had little effect on gene expression. The bent body of the hsp90a2 morphants might not be a specific phenotype as an alternative hsp90a2 MO produced embryos with normal morphology (see Materials and methods). |
Expression Data
| Genes: | |
|---|---|
| Fish: | |
| Knockdown Reagents: | |
| Anatomical Term: | |
| Stage: | Prim-5 |
