Fig. S1

lysC expression during early embryonic/larval development. lysC expression within 22 hpf (A and B), 30 hpf (C-E), 36 hpf (F-H), 48 hpf (I-K), 4 dpf (L-N), 5 dpf (O and P) and 7 dpf (Q and R) zebrafish embryos and larvae. Arrow in D denotes lysC-expressing cell within head mesenchyme. Arrows in O-Q denote lysC transcripts within the developing pronephric glomerulus. Scale bars: 200 μm.

Expression Data

Gene:	lyz
Fish:	WT
Anatomical Terms:	head mesenchyme intermediate cell mass of mesoderm macrophage myeloid cell pronephric glomerulus
Stage Range:	26+ somites to Days 7-13
