Fig. S3

The zebrafish Pax6a BAC transgene exhibits differential promoter activity in the adult mouse retina. DsRed is expressed by a subset of EGFP⁺ cells in the adult mouse retina. Both EGFP and DsRed were visualized by indirect immunofluorescence (EGFP, green; DsRed, red). Arrowheads denote examples of EGFP⁺/DsRed- cells. Horizontal and ganglion cells express EGFP but not DsRed. DsRed is expressed by a subset of EGFP⁺ cells in the both the GCL and INL. Marker analyses presented in this study showed that GABAergic amacrine cells express both DsRed and EGFP; DsRed expressing neurites tend to localize to the middle strata of the IPL (arrow in B). A subset of bipolar cells also coexpresses DsRed and EGFP.
