Fig. 7

Hsp90a and Steif/unc-45b mRNA are up-regulated in steif mutant embryos. In situ hybridization with antisense probes for hsp90a (A?B), a2 (C, D) and steif/unc-45 (E, F). steif mutant embryos (B, D, F) show an up-regulation of hsp90a, a2 and steif/unc-45b transcripts in skeletal muscles. Only hsp90a and a2 expression levels were increased in the heart (arrow and insert in panels A to D). Note that for reasons of quantitative comparisons, the staining reactions had to be terminated before strong signals were detectable in the wild-type embryos. All embryos are 2 days old. Scale bar: 150 mm.

Expression Data

Genes:	hsp90aa1.1 hsp90aa1.2 unc45b
Fish:	WT unc45b^sb60/sb60
Anatomical Terms:	heart somite trunk musculature
Stage:	Long-pec

Expression Detail

Antibody Labeling

Phenotype Data

Phenotype Detail

Acknowledgments

This image is the copyrighted work of the attributed author or publisher, and ZFIN has permission only to display this image to its users. Additional permissions should be obtained from the applicable author or publisher of the image.

Reprinted from Developmental Biology, 308(1), Etard, C., Behra, M., Fischer, N., Hutcheson, D., Geisler, R., and Strähle, U., The UCS factor Steif/Unc-45b interacts with the heat shock protein Hsp90a during myofibrillogenesis, 133-143, Copyright (2007) with permission from Elsevier. Full text @ Dev. Biol.
