Fig. 4

Zygotic nos1 is required for adult germline maintenance. Histology of 6-month-old females (A and B) and male (C and D) gonads. (A) Wild-type ovaries contain oocytes (stages indicated). (B) nos1 mutant females do not contain oocytes. The testes of wild-type (C) and nos1 mutants (D) are indistinguishable. Three-month-old wild-type (E, G and I) and nos1 mutant (F, H and J) ovaries freshly isolated (E and F) or stained for vasa (G and H) or ziwi (I and J) RNA. Wild-type ovaries contain numerous stage I oocytes, visualized as small (7?140 μm diameter) clear cells on the surface of the ovary (E) or as small vasa RNA⁺ (G) and ziwi RNA⁺ (I) cells (arrows). In contrast, nos1 mutant ovaries contain very few stage I oocytes (F, H, J; arrows in panels H and J). RNA in situ hybridization to detect vasa RNA reveals that 35 dpf nos1 mutant ovaries (L) contain fewer < 20 μm germ cells (arrow) than wild-type ovaries (K). sg, spermatogonia; sp, sperm; l, liver. Scale bars: 100 μm in panels A?D, K, L; 200 μm panels in E?J.

Expression Data

Genes:	ddx4 piwil1
Fish:	AB nanos3^fh49/fh49 (AB)
Anatomical Term:	ovarian follicle stage I
Stage Range:	Days 30-44 to Adult

Expression Detail

Antibody Labeling

Phenotype Data

Fish:	nanos3^fh49/fh49 (AB)
Observed In:	oocyte testis
Stage:	Adult

Phenotype Detail
