Fig. 1
- ID
- ZDB-FIG-060203-16
- Publication
- Cunliffe et al., 2006 - Histone deacetylase 1 is essential for oligodendrocyte specification in the zebrafish CNS
- Other Figures
- All Figure Page
- Back to All Figure Page
Histone deacetylase 1 is required for specification of oligodendrocytes in the zebrafish hindbrain and for expression of sox10 in neural progenitor cells of the ventral hindbrain. (A–D) dorsal views of hindbrains of wild-type (A,C) and hdac1 mutant (B,D) embryos, anterior is uppermost. (E,F) Transverse sections through hindbrain of (E) wild-type and (F) hdac1 mutant embryos at the level of rhombomere 5. A symmetrically distributed population of dispersed cells expressing the oligodendrocyte differentiation marker plp1b is present in the hindbrain of wild-type sibling embryos (A) but completely absent in hdac1 mutants (B), at 4.5 days post-fertilization (dpf). Likewise, sox10-positive neural progenitors are readily visible throughout the ventral medial part of the wild-type hindbrain (C,E) but absent in the hindbrain of hdac1 mutant embryos (D,F), at 50 hpf. |
| Genes: | |
|---|---|
| Fish: | |
| Anatomical Terms: | |
| Stage Range: | Long-pec to Day 4 |
Reprinted from Mechanisms of Development, 123(1), Cunliffe, V.T., and Casaccia-Bonnefil, P., Histone deacetylase 1 is essential for oligodendrocyte specification in the zebrafish CNS, 24-30, Copyright (2006) with permission from Elsevier. Full text @ Mech. Dev.
