Fig. 2

RNA in situ hybridization analysis of 72 hpf zebrafish embyros. (A) Lack of whna expression in thymic rudiment; note expression in developing eye and brain structures. (B) Expression of whnb in third branchial arch; arches are indicated by Roman numbers. (C) Transverse section through thymic primordium indicating the location of whnb-expressing cells (purple). ov, otic vesicle; ph, pharynx; no, notochord; y, yolk (with non-specific staining); op, operculum. Only one half of the section is shown. (D–F) Expression of whnb in developmental mutants. D, wild-type embryo. E, cloche mutant; F, casanova mutant.

Expression Data

Genes:	foxn1 foxn4
Fish:	WT sox32^ta56/ta56 npas4l^m378
Anatomical Terms:	brain eye thymus thymus primordium
Stage:	Protruding-mouth

Expression Detail

Antibody Labeling

Phenotype Data

Fish:	npas4l^m378
Observed In:	thymus thymus primordium
Stage:	Protruding-mouth

Phenotype Detail
