ZFIN Image: Cai et al., 2012, Fig. S1


Figure Caption

Fig. S1 Expression patterns of crabp2a and crabp2b. (A-L) Whole-mount in situ hybridizations for crabp2a (A-F) and crabp2b (G-L), lateral views, anterior to the left, of embryos between 8.5 (A,G) and 24 (F,L) hpf. crabp2a is first detected in the posterior hindbrain and anterior spinal cord at 10 hpf (B), and expression expands anteriorly and posteriorly from 12-24 hpf (C-F). crabp2b is broadly expressed during gastrulation (G), becomes excluded from the anterior head by 10 hpf (I), and later is largely restricted to R2 at 12 hpf (J) and to newly formed somites and the tail by 15 hpf (K,L). (M,N) Flat-mounted embryos, dorsal views, co-labeled for krox20 (red) and crabp2a (M) or crabp2b (N) at 12 hpf. E, eye; HB, hindbrain; R3-5, rhombomeres 3-5; SC, spinal cord; SO, somites.

Figure Data

Expression / Labeling details
