ZFIN Image: Heisenberg et al., 1997, Fig. 7


Figure Caption

Fig. 7 In slb/tri double mutants the slb eye phenotype is strongly enhanced. (A, D) Frontal view of a tri (A) and slb/tri (D) double mutant at 48 hpf. (B, E) The anlage of the optic stalks expressing pax2 in a tri (B) and slb/tri (E) double mutant at 15 hpf. Dorsal views, anterior to the left. (C, F) The axonal scaffold stained for acetylated tubulin appears normal in a tri (C) mutant and is still intact but strongly deformed in a slb/tri (F) double mutant at 24 hpf (the small picture in the upper right corner of F shows a dorsal view of the axonal scaffold stained for acetylated tubulin in slb/tri embryos at 24 hpf). Side views, anterior to the left.

Figure Data

Phenotype details

Acknowledgments

This image is the copyrighted work of the attributed author or publisher, and ZFIN has permission only to display this image to its users. Additional permissions should be obtained from the applicable author or publisher of the image.

Reprinted from Developmental Biology, 184(1), Heisenberg, C.P. and Nüsslein-Volhard, C., The function of silberblick in the positioning of the eye anlage in the zebrafish embryo, 85-94, Copyright (1997) with permission from Elsevier. Full text @ Dev. Biol.
