Figure Caption
Fig. 3 Expression of vox and vent in dorsalized zebrafish mutants. (A–F) Expression of vox and vent in 70% epiboly embryos, lateral view, dorsal is to the right. (A, B) Wild-type (wt) embryos. (C, D) swirl (swr) mutants. (E, F) somitabun (sbn) mutants. Note that the marginal expression of vox is retained in swr (C) and sbn (E) embryos. (G–J) Expression of vox and vent in 100% epiboly embryos, vegetal view, dorsal is to the top. (G, H) Wild-type embryos. (I, J) snailhouse (snh) embryos. Note that the expression level is reduced in snh embryos but the pattern of expression is unchanged.
Figure Data
Acknowledgments
This image is the copyrighted work of the attributed author or publisher, and
ZFIN has permission only to display this image to its users.
Additional permissions should be obtained from the applicable author or publisher of the image.
Reprinted from Developmental Biology, 224(2), Melby, A.E., Beach, C., Mullins, M., and Kimelman, D., Patterning the early zebrafish by the opposing actions of bozozok and vox/vent, 275-285, Copyright (2000) with permission from Elsevier. Full text @ Dev. Biol.
