Fig. 3
Expression of vox and vent in dorsalized zebrafish mutants. (A–F) Expression of vox and vent in 70% epiboly embryos, lateral view, dorsal is to the right. (A, B) Wild-type (wt) embryos. (C, D) swirl (swr) mutants. (E, F) somitabun (sbn) mutants. Note that the marginal expression of vox is retained in swr (C) and sbn (E) embryos. (G–J) Expression of vox and vent in 100% epiboly embryos, vegetal view, dorsal is to the top. (G, H) Wild-type embryos. (I, J) snailhouse (snh) embryos. Note that the expression level is reduced in snh embryos but the pattern of expression is unchanged. |
Expression Data
| Genes: | |
|---|---|
| Fish: | |
| Anatomical Terms: | |
| Stage Range: | Shield to Bud |
Expression Detail
Antibody Labeling
Phenotype Data
| Fish: | |
|---|---|
| Observed In: | |
| Stage Range: | Shield to Bud |
Phenotype Detail
