FIGURE

Fig. 1

ID

ZDB-FIG-180424-10

Publication

Eachus et al., 2017 - Genetic disruption of 21-hydroxylase in zebrafish causes interrenal hyperplasia

Other Figures

All Figure Page

Back to All Figure Page

Fig. 1

Zebrafish cyp21a2 expression is largely restricted to the interrenal gland. (a) Analysis of cyp21a2 expression during embryonic and early larval development by RT-PCR with b-actin1 as an internal standard (gel images inversed). A no-template control sample (NTC) served as negative control. The onset of detectable cyp21a2 expression is at 28 hpf, after which cyp21a2 continues to be expressed at all stages examined. (b) Images of wild-type larvae at different stages after WISH against cyp21a2. Left panels show lateral view, with head to the left; right panels show a dorsal view. No staining is seen in 24-hpf embryos. In 28-hpf embryos and 120-hpf larvae, strong staining is observed in the interrenal gland region, with some faint signal detected at 120 hpf in the head (arrows). Scale bar: 0.1 mm.

Expression Data

Gene:	cyp21a2
Fish:	WT
Anatomical Terms:	head interrenal gland interrenal primordium whole organism
Stage Range:	1-cell to Day 5

Expression Detail

Antibody Labeling

Phenotype Data

Phenotype Detail

Acknowledgments

This image is the copyrighted work of the attributed author or publisher, and ZFIN has permission only to display this image to its users. Additional permissions should be obtained from the applicable author or publisher of the image. Full text @ Endocrinology
