Stage Range: Prim-5 to Protruding-mouth

Fig. 6

Rab38s expression pattern during zebrafish embryogenesis. Rab38a is expressed across the pharyngula embryonic period (24–48 hpf) (a-d): at 24 hpf there is a faint signal in RPE (arrowhead) and a strong one in migrating melanoblasts (a, b, white arrowhead) and a low level of expression is detectable in the mid-ventral region of brain (a); at 48 hpf the expression is visible only in the RPE (black arrowhead) (c, d). Rab38b is expressed only at late developmental stages (e-h): at 48 hpf in a small region of the pharyngeal arches (white arrow) and in the developing swim bladder (e, f, white asterisks), while at 72 hpf only in swim bladder (g, h, white asterisks). The gene Rab38c gene is strongly expressed in the head region (i and j for 24 hpf larvae). Lateral view in all images (anterior is on the left) except d and f that are ventral (anterior on the top)

Gene Expression Details
Gene Antibody Fish Conditions Stage Anatomy Assay
rab38a WT standard conditions Prim-5 brain ventral region ISH
Prim-5 melanoblast ISH
Prim-5 neural crest cell ISH
Prim-5 presumptive retinal pigmented epithelium ISH
Long-pec retinal pigmented epithelium ISH
rab38b WT standard conditions Long-pec pharyngeal arch ISH
Long-pec swim bladder bud ISH
Protruding-mouth swim bladder ISH
rab38c WT standard conditions Prim-5 head ISH
