Fig. S2

(A and B) Tg(flk1:EGFP)^s843 embryos, where GFP expression at 48 hpf marks endocardial cells and endothelial cells in blood vessels. Blood vessels between the somites and within the head appear similar in control (A) and miR-138-morpholino injected fish (B). (dv, dorsal vessels; h, head; ht, heart; isv, intersomitic vessels.)
