Fig. 5

Daggett et al., 2007 - Control of morphogenetic cell movements in the early zebrafish myotome
Other Figures
All Figure Page
Back to All Figure Page
Fig. 5

cap1 expression is enriched in adaxial cells prior to and during their pre-migratory behaviors and is dependent on Hedgehog signaling. (A) In a 5-somite stage wild-type embryo, cap1 is expressed specifically in the adaxial cells of both newly formed somites (upper arrowhead) and the presomitic mesoderm (lower arrowhead). (B) At the 12-somite stage, cap1 continues to be expressed within the adaxial cells of somitic and presomitic mesoderm (arrowheads), and becomes increasingly upregulated in the overlying ectoderm. (C) 10-somite stage embryos showing cap1 expression in wild-type (left) and yot mutant (right) embryos. cap1 is not expressed in the adaxial cells of yot mutants (arrowheads), which are deficient in Hedgehog signal transduction.

Expression Data
Anatomical Terms:
Stage Range: 5-9 somites to 10-13 somites

Expression Detail
Antibody Labeling
Phenotype Data

Phenotype Detail
This image is the copyrighted work of the attributed author or publisher, and ZFIN has permission only to display this image to its users. Additional permissions should be obtained from the applicable author or publisher of the image.

Reprinted from Developmental Biology, 309(2), Daggett, D.F., Domingo, C.R., Currie, P.D., and Amacher, S.L., Control of morphogenetic cell movements in the early zebrafish myotome, 169-179, Copyright (2007) with permission from Elsevier. Full text @ Dev. Biol.
