Fig. 4

Cranial and lateral line ganglion nerves in a control embryo (A,B) and an embryo injected with RcadMphA (C,D), as demonstrated by anti-acetylated tubulin immunostaining (an-tub). All panels are lateral views of the hindbrain region with anterior to the left and dorsal up. A and B, C and D are from the same embryos, respectively, with A and C focusing on the gV/AD nerves, and B and D focusing on the gX and gP nerves. nADb, buccal ramus of the anterodorsal lateral line nerve; nADso, superior ophthalmic ramus of the anterodorsal lateral line nerve; nAVm, mandibular ramus of the anteroventral lateral line nerve; nIX, glossopharyngeal nerve; nP, posterior lateral line nerve; nVDl, dorsolateral nerve of the trigeminal ganglion; nX, vagus nerve; rX, vagus root. Other abbreviations are the same as in Figures 1 and 2.

Expression Data

Expression Detail

Antibody Labeling

Phenotype Data

Fish:	WT + MO1-cdh4
Knockdown Reagent:	MO1-cdh4
Observed In:	cranial nerve lateral line nerve
Stage:	Long-pec
